1
28104030044BA
Swing Arm Sub Assy Duke 390 MY
0 Kč
2
J011050133
HH COLLAR SCREW M5X13 SW8
0 Kč
3
94513047010
clamp hose
0 Kč
4
93004060100
Chain cover
0 Kč
5
90104037000
Shaft swing arm L=299mm
0 Kč
6
90104038000
FLANGED NUT M14X1.5
0 Kč
7
J025060081
Hex collar screw M6X8
0 Kč
8
93004051000
Supporting shell
0 Kč
11
93004042000
Special wahser
0 Kč
12
90104046000
swingarm adjusting ring
0 Kč
13
90104034001
OIL SEAL RING 25X32X7
0 Kč
14
90104036000
Thrust washer 22.2x31.7x1
0 Kč
15
90104034000
cup for radial shaft seal
0 Kč
16
90104031000
Igus plain bearing
0 Kč
17
90104032000
sleeve bushing 15.1x20x38
0 Kč
18
90104010002
flanged hex nut M10x1.25 WS13
0 Kč
19
90104040000
BOLT HEX M10X1.25X50 WS10
0 Kč
20
93004064000
Plastic screw 6x30
0 Kč
21
93004065000
hexagon socket screw M5X0.8X55
0 Kč
22
90604062000
chain slider bushing
0 Kč
23
J025060169
HH COLLAR SCREW M6X16 SW8
0 Kč
24
93013047000
Support
0 Kč
25
J912050141
bolt socket-m5x0.8xl 14xprecoa
0 Kč
27
90204060001
HH COLLAR NUT
0 Kč
28
90104040100
screw M5x0.8x30
0 Kč
29
90504067000
WASHER CHAIN SLIDING GUARD
0 Kč
30
90104070020
SLEEVE CHAIN GUARD
0 Kč
31
90904070020
SLEEVE CHAIN GUARD
0 Kč
32
90804066000
chain slider
0 Kč
98
90104230010
SWINGARM REP. KIT 11-17
0 Kč
